Sigillatrice ad aria calda SM series

semiautomaticaper derrate alimentariper sacchi

Pneumatic Sealer SM 35/40A Pneumatic sealer SM 35/40 A for closing bags of any material using an aluminum strip with a height of 5/7 mm. All contact parts are made of AISI 304 stainless steel suitable for food contact.The seal is made from a high-autonomy coil, cut to a length of 35/40 mm, wrapped around the neck of the bag, and finally pressed to form a flat closure.The machine is prepared for an optional kit available at the time of order, which includes a date marker and numeric punches.Available models:SM 35 A 5: Aluminum seal width 5 mm - thickness 0.6 mm - length 35 mmSM 40 A 7: Aluminum seal width 7 mm - thickness 0.6 mm - length 40 mmMODELSM 35 A - 5 mmSM 40 A - 7 mmMachine power supplyPneumaticPneumaticAir consumption50 liters/minute50 liters/minuteOperating pressure6 bar6 barMaximum closing speed30 pcs/min30 pcs/minAluminum seal dimensionsWidth 5 mmThickness 0.6 mmLength 35 mmWidth 7 mmThickness 0.6 mmLength 40 mmAutonomyabout 2800 closuresabout 2500 closuresAluminum strip length100 m100 mDate marker with1 writing line for day/month/year or batch2 writing lines for day/month/year and batchType of closureFlat, aesthetically elegant sealMachine dimensions600x500x990h mm600x500x990h mmMachine weight45 kg45 kgPrinting line12Punches included in the optional kitThe characters included in the kit are those indicated in the following table (numeric) with a height of 2.5 mm.The characters are only sold in complete kits. It is not possible to request individual characters.STANDARD CHARACTERSQUANTITY N°STANDARD CHARACTERSQUANTITY N°04521462257232824292Technical Specifications / FeaturesPneumatic operationAir consumption: 50 liters/minuteOperating pressure: 6 barMaximum closing speed: 30 pcs/minAluminum seal dimensions: 5 mm x 0.6 mm x 35 mm or 7 mm x 0.6 mm x 40 mmAutonomy: about 2800 (SM 35 A 5) or 2500 (SM 40 A 7) closuresAluminum strip length: 100 mDate marker: 1 or 2 writing linesType of closure: Flat, aesthetically elegant sealMachine dimensions: 600x500x990h mmMachine weight: 45 kgPunch kit (optional): numeric characters, height 2.5 mm, sold only in complete kits
