PRESSIONE PFA/PS in bar θ 100°
CORPO : ghisa GJL rivestimento Epoxy
OTTURATORE : 2 a 3 bronzo, altri DN : ghisa con asse in bronzo
GUIDA : 21/4 a 21/2 bronzo, altri DN ghisa con annello in bronzo
MOLLA : acciao inossidabile - GUARNIZIONE : EPDM
GRIGLIA : acciaio galvanizzato
PRESSIONE PFA/PS in bar θ 80°
CORPO : ghisa GJL rivestimento Epoxy
OTTURATORE : conforme modelli 102
GUIDE : conforme modelli 102
MOLLA : acciao inossidabile
GUARNIZIONE : EPDM
GRIGLIA : PP (polipropilene)
PRESSIONE PFA/PS in bar θ 80°
CORPO : ghisa GJL rivestimento Epoxy
OTTURATORE + GUIDA : conforme modelli 102
MOLLA : acciao inossidabile
GUARNIZIONE : elastomero fluorato
GRIGLIA : PP (polipropilene)
PRESSIONE PFA/PS in bar θ 100°
CORPO : ghisa GJL rivestimento epoxy, 2 prese non forate
GUARNIZIONE : EPDM - MOLLA : acciaio inossidabile (tipo 202)
OTTURATORE : DN 21/2 e 3 : bronzo, DN 4 : ghisa con asse in bronzo
GUIDA : DN 21/2 : bronzo, altri DN : ghisa con anello in bronzo
PRESSIONE PFA/PS in bar θ 100°
CORPO : ghisa GJL rivestimento PTFE interno e esterno
2 prese filettate con tappi 1/4
GUARNIZIONE : NBR (nitrile) o EPDM
OTTURATORE + GUIDA : ghisa GJL rivestimento PTFE
DN 50 e 65 otturatore bronzo
PRESSIONE PFA/PS in bar θ 100°
CORPO : ghisa GJL rivestimento Epoxy
2 prese non forate
GUARNIZIONE : elastomero fluorato
OTTURATORE + GUIDA : conforme ai modelli standard tipo 202
PRESSIONE PFA 40 bar / PS in bar θ 100°
CORPO : ghisa GJS + rivestimento Epoxy
GUARNIZIONE : EPDM
OTTURATORE : bronzo
GUIDA : DN 21/2 : bronzo
DN > : guida in ghisa con anello bronzo
