Magazzino rotante verticale

per tubiper tessiliper rotoli tessili

Vertical Rotating Storage – Automatic Vertical Warehouse for ROLLS – REELS Vertical rotating warehouse for rolls and reels, perfect for storing flexible floor coverings, technical fabrics (fiberglass, tarpaulins, coated fabrics…), winders/packaging machines, and much more. Applications: - Flexible floor coverings - Technical fabrics (fiberglass, tarpaulins, coated fabrics, etc.) - Winders/packaging machines Storage Method: - On a shaft adapted to the internal diameter of your core, a load calculation defines the appropriate shaft diameter to avoid bending. - The material can be pulled directly from the rotating carousel using a textile cutter, a visitor machine, or on a simple table for end cutting and quilting. - The position of the axes is adjustable on the transport chain, offering great flexibility for warehouse optimization. - Available in a single loop or multiple successive loops depending on the total accumulated load. Options and Accessories (depending on configuration): - Centering cones - Guide disc - Shaft on bearing - Retention belts - Label holders - Cycle start/end variator (depending on total load) - Cell barrier - Double front/rear control - Manual or automatic cutting table - Measuring system - Unwinding cradle - Unwinder for rolls: trolley, crank, etc. Loading/Unloading: - With a specially designed handling trolley that allows ergonomic bottom loading, various types of trolleys are available, including battery-powered handling trolleys. Technical Features: - 13 device heights available - 5 ranges available depending on maximum diameter - 3 types of transport chain - Maximum weight: 1000 kg - Maximum diameter: 980 mm - Total length: from 2 to 6.5 meters - Linear speed: between 4 and 6.10 m/min max - Control: maintained action or automatic - Power supply: 220v or 380v – from 0.55kw to 1.5kw Specification Items: - Outer roll diameter - Inner roll diameter - Maximum width - Maximum weight - Quantity to store - Single or double access use - Available height - Manual or automatic cutting table supply - Maintained action or PLC control - Other possible limitations (ATEX zone, electrical regime, etc.) Advantages: - Easy to use: The default maintained action control allows access to the desired item. Can be used in both rotation directions. - Accurate management: No risk for your employees, ergonomic working height during loading or unloading. - Quick access: In prolonged action or via an automaton with an item code, quickly reach the desired reference. - Space optimization: Take advantage only of the height of your building. - Inventory control: Quick inventory of your warehouse; possible integration with ERP/WMS for optimized management. - Storage of heavy and bulky products: Specific solutions for every application. Technical Specifications (summary): - 13 device heights available - 5 ranges by maximum diameter - 3 types of transport chain - Maximum weight: 1000 kg - Maximum diameter: 980 mm - Total length: 2 to 6.5 meters - Linear speed: 4 to 6.10 m/min max - Control: maintained action or automatic - Power supply: 220v or 380v – 0.55kw to 1.5kw
