Sistema operativo - ctrlX OS
Processore - Zynq UltraScale+, 64 bits, 4 × ARM A53
Memoria principale (RAM) - 2 GB, DRAM
Memoria interna (flash) - 4 GB, eMMC
Memoria hardware non-volatile - 128kbyte
Tipo scheda di memoria - microSD fino a 32 GB (tutte le caratteristiche garantite sono valide solo con la scheda di memoria WAGO)
Interfacce (USB) - 1 x USB host, type C (USB2.0), maximum cable length: 3 m
Tensione di alimentazione - 24 VDC, SELV/PELV (18 … 31,2 V); (includes all tolerances, including ripple); Internal fuse protection with eFuse, 1.5 A; Overvoltage protection: the fuse can trip in the event of overvoltage; Transient protection: suppressor diodes; Pulse load up to 1500 W; Voltage drops on power supply interfaces: PS1 < 1 ms; Evaluation criterion A
Categoria sovratensione - 2 per IEC 60664-1
Assorbimento energia (tip.) - 320 mA
Assorbimento energia tip. (24 V) - 7,68W
Isolamento - 707 VDC (24 V supply to functional ground); 1200 VDC (24 V supply to XF10, XF50, XF51)
