Telefono analogico

IP66per ascensoreper galleria

Model
Five way intercom with Master

Size

Material

Introduction
The elevator Intercom system will be applied to elevator emergency or maintenance application. Also applicable for shipping center, bus terminal, car park center, tunnel construction, etc. Power supply: Centralized DC 12V or AC 110~220v AC

Operating Instructions

• Master station call elevator phone: Pick up the master station handset, press the elevator phone number and speak to it. Press * to speak to all elevator phones. Elevator phone will auto stop when master station hang up.
• Elevator phone call Master station: press call button or pick up hand, the phone will automatically call master station. Both master will ring. Elevator phone will auto stop when master station hang up.
• Master1 call Master2: Pick up the handset of the Master1, then press the other master station phone number, Master2 rings, speak to it.

Specification

• Working Voltage: DC12V
• Operating Current: ??300mA
• Maximum Power Consumption: 2W
• Noise Voltage: ??1OmV
• Communication Distance: ??2000m
• Ringing Level: ??7OdB
• Working Condition: Ambient Temperature: -40????60??; Relative Humidity: 30%??95%
• Ambient Noise: 60 dB; Line Number: double core line
• Description for the wire: single line resistance can’t more than 50 Ohm.

Wire requirements
Require all connecting the kingdom line, multicore parallel lines can meet the general engineering requirements. When walking line and strong power line interference serious environmental mixed wiring, the shielding measures should be adopted to keep distance and take more than 30 cm.

Certification

• EMC: EN50121 (Railway application- Electromagnetic Compatibility)
• EN55022: emissions
• EN55024: immunity
• Ingress Protection: GB4208-93 IP66
• FCC
• ITU-T Recommendations K21

Packing details

• 1 pcs in each inner CTN box; size: 43.3 x 27.6 x 19.1; G.W: 4kg
• 4 pcs in outer CTN box; size: 56.6 x 44.5 x 42; G.W: 20.25kg
• 20GP: 3000PCS; 40GP: 6000PCS; 40HQ: 7000PCS

Caractéristiques / spécifications techniques

• Model: Five way intercom with Master
• Working Voltage: DC12V
• Operating Current: ??300mA
• Maximum Power Consumption: 2W
• Noise Voltage: ??1OmV
• Communication Distance: ??2000m
• Ingress Protection: IP66
