Chipset
- Intel® C246/H310, TDP 6W
Memoria
-
DDR4-2666, 4*U-DIMM, fino a 64 GB
Supporto ECC con chipset C246
TPM -
TPM 2.0 Onboard (opzionale)
Archiviazione
-
1*M.2 (Key-M, 2242/2280, SSD SATA)
2*SATA 3.0, 1*CF Card
Interfaccia di espansione
-
1*M.2 (Key-E, 2230, Wifi, solo per C246)
1*M.2 (chiave-B, 3042-4G, 3052-5G)
- 1*Slot PCIe x8
PCH PCIe x4, solo per C246
Supporta uno dei seguenti 2 slot PCIe Side Plug
- 1*Slot PCIe x16 a innesto laterale
CPU PCIe x8, PCH PCIe x4, 15*GPIO
- Slot laterale 1*PCIe x8
CPU PCIe x4
BIOS
-
BIOS AMI UEFI
Sistema
-
Windows 10, Linux
Interfaccia I/O
Ethernet
-
6*Controller Ethernet Intel® 1Gbps, RJ45
Supporto 2*Gen3 Lan Bypass
controllore Ethernet 1Gbps 2*Intel®, SFP
2*SFP e PCIe x16 non possono essere supportati contemporaneamente quando il chipset è H310
Seriale
-
2*RS232
USB
-
2*USB 3.0, 2*USB 2.0
PS/2
-
1*PS/2 Header (tastiera e mouse)
GPIO
-
8 GPIO programmabili
Display
Interfaccia display
-
1*HDMI: risoluzione massima fino a 4096*2160@24Hz
1*VGA: risoluzione massima fino a 1920*1200@60Hz
Meccanica e ambiente
Dimensioni -
288*207 mm
Ingresso di alimentazione -
PSU ATX
Temperatura - Funzionamento: 0℃~60℃, Stoccaggio: -25℃~75℃
Umidità relativa
- Funzionamento: 10%~90%, stoccaggio: 5%~95%, senza condensa
---
