Tavola vibrante per calcestruzzo fresco

pneumatica

Equipment for the production by vibrocompression of manufactured products with heights from 250 mm to 2000 mm, demolding with overhead crane or forklift, particularly suitable for the creation of special pieces. Product Presentation: Equipment for production by vibrocompression, with direct demolding via overhead crane/forklift or tilting via spreader beam of a wide variety of concrete products; it is particularly suitable for the production of special pieces. All products that can be produced with semi-dry concrete that respect the maximum capacity, with a maximum height of 2000 mm, can be made, in single mode (on request, multiple production can also be provided). Technical Features: In the standard configuration, the table is equipped with a frame for quick hydraulic fastening of the external molds (and quick mechanical fastening of the internal molds) with a simple and fast system, which allows for daily quick mold changes in very short times (no longer requiring adjustment of the external and internal molds after production change). The concrete feeding can be manual (with a simple conveyor belt controlled by the operator via joystick), semi-automatic (with conveyor belt complete with rotating distributor), or automatic (with conveyor belt complete with secondary rotating belt, managed by PC, with software to feed the mold following the external perimeter. This last solution is particularly effective in the production of box culverts and special products). Another feature that makes the vibrating table system extremely functional is the regulation of vibration both mechanically and electronically via inverter and the electronic regulation of the conveyor belt feeding speed (where provided). The general management and control of the machine can be, on request for more complex configurations, performed via PC Vicom system, with synoptics for machine status and anomaly control, complete with modules for remote assistance. Products that can be made: - All products (with any type of joint) to be produced with semi-dry concrete, with a max height of 2000 mm, that respect the maximum capacity (from 2 to 42 tons, depending on the various models) Advantages: - Cost-effectiveness - Flexibility (a wide range of products can be made; ideal machine for the production of both large-sized products, due to its characteristics, and medium-small sized products, due to its cost-effectiveness and practicality) - High product quality guaranteed by automatic electronic regulation of vibration and concrete feeding - Very fast internal mold change (the reduced times allow for practically immediate mold change), without the need for mold adjustment after the change - Ease of use and maintenance - Possibility to use existing molds, even if not produced by Colle - System that does not require foundation work - Possibility to have (on request for more complex configurations) complete plant control via PC Vicom system, with the possibility of remote production management Technical Data Sheet: VIBRATING TABLES | DAMPING | SPECIAL FEATURES | TOTAL CAPACITY | USEFUL CAPACITY 1200 x 1200 | n°1 vibrating group | Mechanical | - | 3 ton | 2.4 ton 1200 x 1700 | n°1 vibrating group | Mechanical | - | 3 ton | 2.2 ton 1200 x 1700 | n°2 vibrating groups | Mechanical | - | 6 ton | 5.1 ton 1500 x 2100 | n°2 vibrating groups | Pneumatic | - | 6 ton | 4.3 ton 1500 x 2100 | n°3 vibrating groups | Pneumatic | - | 9 ton | 7.2 ton 1700 x 2800 | n°2 oversized vibrating groups | Pneumatic | Self-leveling | 12 ton | 9.5 ton 1700 x 2800 | n°3 oversized vibrating groups | Pneumatic | Self-leveling | 18 ton | 15.4 ton 2340 x 3000 | n°4 oversized vibrating groups | Pneumatic | Self-leveling, Hydraulic drive | 25 ton | 20.9 ton 3000 x 5000 | n°4+4 oversized vibrating groups | Pneumatic | Self-leveling, Hydraulic drive | 50 ton | 41.8 ton - Production by vibrocompression for products from 250 mm to 2000 mm in height - Demolding with overhead crane or forklift - Suitable for special pieces and a wide variety of concrete products - Quick mold change system - Manual, semi-automatic, or automatic concrete feeding - Mechanical and electronic vibration regulation - Electronic conveyor speed regulation (where provided) - Optional PC-based control and remote assistance - Capacity from 2 to 42 tons depending on model
